555nm

-2
-2

555nm

Features:

· Gaussian Line

· Wide Temperature Range

· Fast Rise Time

· High Reliability

Product Details:

Dimensions (Unit: mm):



Product Specifications:


SpecificationG555L015-17x35-120-(-10-50)-10
Wavelength555 ± 4 nm
Output Power> 15 mW
Spatial ModeMulti
Laser Class3R
Residual IR1%
Line width @ 7m (mm)<4
Deviation of Laser Beam at 10m (mm)<2
Line Curvature (mm) at 10m< ±1
Fan Angle (1/e 2 , degree) (120
Warm-Up Time (seconds)< 0.2
Polarization Ratio> 100:1
Laser Drive ModesCW / Pulsed
Power TypeACC-CW input / ACC-TTL (50% duty cycle - it can not be adjusted, 110Hz)
Operating Temperature (℃)-10 to 50
Storage Temperature (℃)-40 to 60
Weight (g)11.6
Lifetime (hours) (MTTF at 25℃)>10000
