High Stability 405nm laser used in the applicaiton of flow cytometry

Contact Us

Fax:

+86 532 66731599

6d2383af71fcd27ff4276255adda9b2
1d6bcc5d327dd94c319ba818c29c059
d575efa1b1d013022b43f9043dfc1c1
6d2383af71fcd27ff4276255adda9b2
1d6bcc5d327dd94c319ba818c29c059
d575efa1b1d013022b43f9043dfc1c1

450nm

Applications

· Life Science

· Scientific Experiment

. Optical Instrument

. Laser Display


Product Details:

Dimensions (Unit: mm):





Product Specifications:


SpecificationB450D050-40x20x10-1.0
Wavelength450 ±5 nm
Output Power45 - 55 mW

Bandwidth

2 mm
M² (Beam Quality)1.3 - 1.7

PK - PK Power Stability(25℃,1h)

1% - 3%

RMS Noise(10MHz,5s)

0.1% - 0.5%
Beam Divergence (full-angle) 0.3 - 0.5mrad

Beam Side Lobes

≤ 3%

Returned Beam Isolation (dB)

40 - 60

Operating Voltage

DC12V

Operating Current

2 A
Output Power Controlcan be customized

Operating Temperature (℃)

10 to 40

Warm-up Time (minutes)

< 5

Lifetime (h) (MTTF at 25℃)

5000 to 10000
