532nm

Applications

· Life Science

· Scientific Experiment

. Optical Instrument

. Medical Laser

Inquire Now Download

Share To：

Product Details:

Product Specifications:

Specification	G532D010-65x25x40-1.
Wavelength	532± 2nm
Output Power	9-11mW
RMS Power Stability（8h,@RT ∆T<3℃）	1.7-2.5%
RMS Noise（20Hz-2MHz	0.041-0.3%
Pk-Pk Noise（20Hz-2MHz	0.07-0.5%
Beam Mode Quality M	1.3-1.4
Vertical Beam Diameter @1/e2(μm)(at V-focal plane	25±5
Horizontal Beam Diameter @1/e2(μm)(at V-focal plane)	375±15
Vertical Beam Diameter @1/e2(μm)(at plane 14.2mm from V-focal plane	317-320
Polarization Orientation（Vertical）(°)	2 - 5
Warm-up Time(Min)（Cold start environmental temperature 15-30℃）	3 - 4
Beam Pointing Stability(urad/℃)	3.6 - 5
Static Beam Height from Base Plate (mm)	19±0.5
Working Distance（mm	17.5 - 19.3
Static Beam Alignment (mrad)	4.6 - 5
Static Beam Alignment (mm)（at 130mm from front panel）	0.5 - 1
Operating Voltage (V)	220
Operating Current (mA)	70-100
Expected Lifetime	10,000 hours
